Best Practices for Installing a TV on the Lift

Modified on Thu, 31 Jul at 10:23 AM

Roller Top Assembly with a piano hinged lid :

  • The TV needs to be placed BELOW the roller



  • This will ensure that when the lift extends out of the cabinet the Lid will touch the roller top assembly and not the TV


Flat Top Lid Mount:

  • The TV needs to be placed under the Flat Top Lid Mount



  • If the TV does not fit under the Flat top Lid Mount you can adjust the C-Bracket at the top of the lift. Move it up far enough so that the top of the TV sits under the Flat Mount.

25092 flat top lid mount angled







 Drop Down application with a Flat Top Lid Mount



  • The TV needs to be placed above the Flat Top Lid Mount





  • If the TV does not fit under the Flat top Lid Mount you can adjust the C-Bracket at the top of the lift. Move it up far enough so that the top of the TV sits under the Flat Mount.



25092 flat top lid mount angled
